Northland Orders Railcars from Kiruna Wagon
Kiruna Wagon has designed specialized railcars, shown here, for transporting iron ore concentrates from
Northland Resources’ Kaunisvaara mill in northern Sweden.
Sweden’s Kiruna Wagon, a manufacturer
of railroad rolling stock, has signed an
order for 150 iron-ore railcars with mining
company Northland Resources. The rail-cars are scheduled for delivery between
January 1, 2013, and May 5, 2014. As
reported last month in E&MJ (See
“Northland Finalizes Logistics and Mill
Operational Agreements for Kaunisvaara,”
May 2012, p. 151), Northland also has
an option to buy up to 92 additional rail-cars from Kiruna Wagon.
The railcars, rated at about 98 met-ric tons capacity, will transport iron ore
concentrate from Northland’s transship-ment terminal in Pitkäjärvi, Sweden, to
the ice-free port of Narvik, Norway, a
distance of 226 km.
Kiruna Wagon said the railcars will
be built primarily with high-strength
steels and will have a low tare weight to
maximize payload. The Pitkäjärvi-to-Narvik Malmbanan rail route has a max-imum permitted axle load of 30 mt.
Based on technology that has been
previously proven on the railway, the
wagon features a load “cube” that
differs from the design manufactured by
Kiruna Wagon for LKAB. Kiruna Wagon
notes that, due to the fine particle
size of Northland Resources’ magnetite
concentrate—with 80% of the product
passing 40 micron—bottom discharge is
not practical and consequently a “bas-ket-turning” solution was chosen
instead. When emptying, the cube is
rotated 148° while the frame remains
on the rails. The rotation, along with the
rounded contour of the walls, creates
optimal conditions for effective dis-charge, according to the manufacturer.
The Northland order, comprising
150 wagons, will operate as 75 short-coupled units in 500-m-long train sets.
